GALAX OMEGA GLX1200
*All photos, specifications, contents are used for reference only and are subject to change without notice. Actual products in different countries varies and are best to consult your local distributor / importer for confirmation.
-
CYBENETICS efficiency levels (ETA) PLATINUM Form Factor ATX 3.0 Connector spec Cable: Full Modular 20+4 pin MB power x 1 4+4 pin CPU power x 2 12+4 pin 12VHPWR PCIe 5.0 x 1 (6+2)(6+2) pin PCI-E power x 5 SATA power x 8 Molex x 3 Cable Length 24pin exposed 600mm, & CPU 4+4pin exposed 700mm, others exposed 600mm+150mm Power and Electrical Specs AC Input: 100-240V Total Output: 1200W Protection: OVP, SCP, OPP, UVP, OTP, OCP DC/DC conversion Capacitors 105°C-Rated Capacitors Fan Specs Fan size: 140mm (Fluid Dynamic Bearing) Max. fan speed < 2000 RPM Dimensions 160*150*86mm Weight 1.65kg
Quality & Performance Assured
Quality and performance are at the forefront of our design philosophy, as evidenced by the prestigious Cybenetics and 80PLUS certifications. This rigorous evaluation involves advanced testing in realistic conditions, with over 25,000 readings ensuring unparalleled accuracy, which represents a stringent test of efficiency, noise, and overall performance.
105°C-Rated Capacitors
for Unyielding Stability
Engineered for endurance, our PSU features 105°C-rated quality capacitors, including main capacitors of premium Japanese origin, ensuring reliable performance even in high-temperature environments. This design choice underscores our commitment to delivering a power supply that not only performs exceptionally but also maintains unwavering stability under intense workloads and in harsh environment.
Fully Modular Cable Design
for Enhanced Convenience & Aesthetics
Low Ripple Noise
for Stable Power Quality
Our PSU stands out with its remarkably low ripple noise, significantly surpassing Intel’s stringent standard under demanding load conditions. The minimal ripple noise contributes to the overall reliability and longevity of sensitive computer components, providing a high-quality power solution that enhances the stable performance of gaming and professional computing systems.
Outstanding DC/DC Conversion Efficiency
for Enhanced Performance
Engineered for endurance, our PSU features 105°C-rated quality capacitors, including main capacitors of premium Japanese origin, ensuring reliable performance even in high-temperature environments. This design choice underscores our commitment to delivering a power supply that not only performs exceptionally but also maintains unwavering stability under intense workloads and in harsh environment.
